Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water

200 pieces
MOQ
$11.00/pieces 200-999 pieces
Price
Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1Y
Product Name: All Stainless Steel Pressure Gauge
Size: 100mm
Material: Stainless Steel
Accuracy: 1.6%
Pressure Range: 0~100Mpa,bar,mbar,etc
Customized Support: OEM, ODM, OBM
Thread: 1/2''PT/NPT/G/M
Highlight:

All Stainless Steel Dry Pressure Gauge

,

Dry Pressure Gauge Manometer

Basic Infomation
Place of Origin: Shandong, China
Brand Name: WYYW
Certification: CE ISO
Model Number: Y-100H
Payment & Shipping Terms
Packaging Details: Each gauge packed in one paper box<br>With outer carton box <br>or packed accordiong to client's requirements
Supply Ability: 100000 Piece/Pieces per Month all stainless steel pressure gauge
Product Description

Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water

Product Description

Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 0

Name

all stainless steel pressure gauge

Dials Size

100mm (or dail size made as demand)

Case

Black steel case; brass connection

Pressure

Mpa,other scale units bar, psi, kg/cm2 etc.optional

Ring

Gasket under the window

Movement

Stainless steel

Socket

Stainless steel

Bourdon tube

Phosphor Bronze

Dial plate and pointer

Aluminum

Window

Glass; Plastic

Connection sizes

1/8" for 1.5; 1/4 for 2",2.5" case; 1/2 for 4",6"

Connection threads

Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)

Mounting

Back

Accuracy

1.5"(40mm), 2"(50mm), 2.5(63mm)-2.5%
4(100mm) and 6 (150mm)-1.6%

Pressure limitation

Steady: 3/4x full scale value
Fluctuation:2/3x full scale value
Short time:full scale value

Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 1

Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 2

Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 3

Product Application
  1. Challenging Outdoor Environments and Extreme Operational Conditions

  2. Applications in Environments with Significant Vibration and Pulsation

  3. Equipment for Hydraulic Systems, Pressure Washers, Oil Field Operations, Pumps, Compressors, and Processing Systems

Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 4

Company Information

Qingdao DaZeFengYang Trading Co., Ltd., founded in 2013, headquartered in Qingdao China.This is a professional, young and dynamic import and export trading company. The company focuses on domestic and foreign trade, cooperative production, entrepot trade etc. Our business mainly engaged in hardware and electrical material, instruments, mental materials.

Products are not only continued to meet the domestic market but also exported to Southeast Asia, South Asia, America, Middle East, Oceania throughout the world. Based on our good product quality,sincere services and our hard working on expanding our business throughout the world we already build good business relationship with our customers all over the world.The company also plays an important role in promoting the modernization, the economic and technical exchanges of China.

Warmly welcome friends from all over the world come to visit, contact, and cooperated with us. We sincerely hope: Together let us creating abrighter future!

Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 5Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 6Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 7

Packaging & Shipping

Stainless Steel Pressure Gauge Dry Bottom 1/2"Bsp Use For Air Water 8

Advantages
  1. Advanced Equipment and Professional Technology: We are dedicated to providing high-quality gauges using state-of-the-art equipment and professional technology for customers worldwide.

  2. Outstanding After-Sales Service: Our company is committed to delivering exceptional after-sales support, aiming for long-term trade partnerships.

  3. Rigorous Quality Inspection: All our pressure gauges undergo 100% inspection, and we are proud to have ISO 9001 and UL certifications.

  4. Timely Delivery: We ensure prompt delivery to consistently meet our customers' needs.

  5. Cost-Effective Purchasing: As a skilled manufacturer, we offer a convenient purchasing experience, providing high-quality products at competitive prices.

  6. OEM Orders: Over the years, we have successfully handled numerous OEM orders for prestigious companies in the USA and European markets.
