1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm

100 pieces
MOQ
$12.00/pieces 100-999 pieces
Price
1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1 Year
Customized Support: OEM, ODM, OBM
Movement& Connection: Stainless Steel
Thread: As Required
Connection: Bottom
Size: 60mm
Oil Filling: Unavailable To Fill Oil
Port: Qingdao, Ningbo, Shanghai, Guangzhou
Highlight:

304 Stainless Steel Pressure Gauge

,

Stainless Steel Pressure Gauge Bottom Connection

,

Pressure Gauge Bottom Connection 60mm

Basic Infomation
Place of Origin: Shandong, China
Brand Name: WYYW
Certification: CE,ISO
Model Number: Y-60H
Payment & Shipping Terms
Packaging Details: Each unit in one paper box,30 boxes in one carton.As customer requested.
Supply Ability: 10000 Piece/Pieces per Month
Product Description

304 stainless steel pressure gauge 1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 0

Product Description

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 1

Name

Stainless Steel pressure gauge

Dials Size

1.5"(40mm), 2"(50mm), 2.5“(63mm), 4”(100mm) and 6“ (150mm)

Case

Stainless steel

Pressure range

0 -250Mpa,other scale units bar, psi, kg/cm2 etc.optional

Ring

Non, black steel or chrome plated

Movement

Brass/ Stainless steel

Socket

Brass/ Stainless steel

Bourdon tube

Phosphor Bronze/ Stainless steel

Dial plate and pointer

Aluminum

Window

Glass or Plastic

Connection sizes

1/8 for 1.5" case; 1/4 for 2",2.5" case, 3/8"&1/2" for 4",6"case

Connection threads

Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)

Mounting

Bottom,back and panel

Accuracy

1.5"(40mm), 2"(50mm), 2.5(63mm)-2.5%
4(100mm) and 6 (150mm)-1.6%

Pressure limitation

Steady: 3/4x full scale value
Fluctuation:2/3x full scale value
Short time:full scale value

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 2

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 3

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 4

Product Application

1.Outdoor and severe ambient and process conditions

2.Use where harmful vibration and pulsation are present

3.Hydraulic equipment, pressure washers,oil field equipment, pumps, compressors and process systems

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 5

Company Information

Qingdao DaZeFengYang is one professional pressure gauge and hardware tools manufacturer, who is also one member of China National Hardware Association.



Together with our highly skilled technical experts, we have put an effort to meet the quality of pressure gauge as per GB/T (Chinese Standard) & International Standards requirements, and have already got ISO9001, CE certificate for all our products, including:
pressure gauge, gas regulator, cutting torch and welding torch etc.



Over the passed years development, there is now an impressive selection of products, both special and standard, with keen prices and deliveries, which together with the speedy sales and after sales service make our company attractive to customers all around the world, especially for those distributors and importers from Europe, Southeast Asia,Middle East, America and Australia.



Welcome every friend to call, email us and visit our company. We sincerely hope to create wonderful future together with you.

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 6

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 7

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 8

Packaging & Shipping

1/4"Bsp 304 Stainless Steel Pressure Gauge Bottom Connection 60mm 9

Advantages

1.Advance Equipment and Professional Technology : we are committed to offer the good quality gauges with advance equipment and professional technology for all over the world customers.

2.Best After-sales Service:Our company provide best after-sale service all the time , for our goal is a long trade cooperation term;

3.Serious Inspection Procedure with Excellent Quality: Our pressure gauges all are 100% inspection , we also have passed ISO9001 and UL certificated;

4.Quickly Delivery: Our company provides in-time delivery with , always satisfy customers needs;

5.Convenient Purchase and save cost: We are skillful manufacturer, so it's convenient for you to purchase , We can provide our high quality products with reasonable price;

6.OEM orders: In the past years, we have many OEM orders from very famous company in USA and European market .
