Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2

200 pieces
MOQ
$9.3/pieces 200-999 pieces
Price
Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2
Features Gallery Product Description Request A Quote
Features
Specifications
Customized Support: OEM, ODM, OBM
Material: Stainless Steel Case
Original Place: Made In China
Dial Size: 100mm, Or Made As Requirements
Pressure Range: Made As Requirments, Mpa, Bar, Psi, Kg Etc.
Mount: Bottom
Quality: 1 Year
Accuracy: 1.6%
Highlight:

250kgf/Cm2 Manometer

,

25MPa Manometer

,

Stainless Steel Case Manometer

Basic Infomation
Place of Origin: Shandong, China
Brand Name: WYYW
Certification: CE ISO
Model Number: YTN-100
Payment & Shipping Terms
Packaging Details: pressure meter for oil and gas<br>Each unit is packed in one paper box, 30 box in one carton . As customer requested.
Supply Ability: 100000 Piece/Pieces per Month pressure meter for oil and gas
Product Description

Pressure Gauge Manometer Bezel Stainless Steel Case 0-25MPa 0-250kgf/cm2

Product Description

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 0

Name

Oil filled pressure gauge

Dials Size

63/100mm (or dail size made as demand)

Case

Stainless steel case

Pressure

Mpa,other scale units bar, psi, kg/cm2 etc.optional

Ring

None

Movement

Brass

Socket

Brass

Bourdon tube

Bronze

Dial plate and pointer

Aluminum

Window

Glass

Connection sizes

 1/4 for 2.5" case; 1/2 for 4",6"

Connection threads

Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)

Mounting

Bottom/Back and panel

Accuracy

2.5(63mm)-2.5%1.6%
4(100mm) -1.6%

Pressure limitation

Steady: 3/4x full scale value
Fluctuation:2/3x full sacle value
Short time:full scale value

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 1

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 2

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 3

Product Application

1.Outdoor and severe ambient and process conditions

2.Use where harmful vibration and pulsation are present

3.Hydraulic equipment, pressure washers,oil field equipment, pumps, compressors and process systems

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 4

Company Information

Qingdao DaZeFengYang is one professional pressure gauge and hardware tools manufacturer, who is also one member of China National Hardware Association.



Together with our highly skilled technical experts, we have put an effort to meet the quality of pressure gauge as per GB/T (Chinese Standard) & International Standards requirements, and have already got ISO9001, CE certificate for all our products, including:
pressure gauge, gas regulator, cutting torch and welding torch etc.



Over the passed years development, there is now an impressive selection of products, both special and standard, with keen prices and deliveries, which together with the speedy sales and after sales service make our company attractive to customers all around the world, especially for those distributors and importers from Europe, Southeast Asia,Middle East, America and Australia.



Welcome every friend to call, email us and visit our company. We sincerely hope to create wonderful future together with you.

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 5

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 6

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 7

Packaging & Shipping

Bezel Stainless Steel Case Manometer Gas Pressure 0-25MPa 0-250kgf/Cm2 8

Advantages
  • Advanced Equipment and Professional Technology: We are dedicated to delivering high-quality gauges using state-of-the-art equipment and professional technology to customers worldwide.

  • Outstanding After-Sales Service: Our company is committed to providing exceptional after-sales support, as we aim for long-term trade partnerships.

  • Thorough Inspection Procedures with Superior Quality: All our pressure gauges undergo 100% inspection, and we are proud to hold ISO9001 and UL certifications.

  • Timely Delivery: We ensure prompt delivery to consistently meet our customers' needs.

  • Convenient Purchasing and Cost Savings: As an experienced manufacturer, we make purchasing easy and offer high-quality products at competitive prices.

  • OEM Capabilities: Over the years, we have successfully fulfilled numerous OEM orders for well-known companies in the USA and European markets.
