Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale

1000 pieces
MOQ
$1.40/pieces 1000-9999 pieces
Price
Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1 Year
Customized Support: OEM, ODM
Material: Black Steel
Original Place: Made In China
Dial Size: 60mm, Or Made As Requirements
Pressure Range: Made As Requirments, Mpa, Bar, Psi, Kg Etc.
Mount: Bottom Mount
Thread: 1/4"BSP NPT
Highlight:

2.5” Dry Pressue Gauge

,

Double Scale Dry Pressue Gauge

,

Vertical Dry Pressue Gauge

Basic Infomation
Place of Origin: Shandong, China
Brand Name: WYYW
Certification: CE ISO
Model Number: Y-60
Payment & Shipping Terms
Packaging Details: 10 bar pressure gauge<br>Each unit is packed in one paper box, 30 box in one carton . As customer requested.
Supply Ability: 100000 Piece/Pieces per Month 10 bar pressure gauge
Product Description

10 bar pressure gaugeDry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 0

Product Description

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 1

Name

High presure gauge from China

Dials Size

60mm (or dail size made as demand)

Case

Black steel case

Pressure

Mpa,other scale units bar, psi, kg/cm2 etc.optional

Ring

None

Movement

Brass

Socket

Brass

Bourdon tube

Phosphor Bronze

Dial plate and pointer

Aluminum

Window

Glass

Connection sizes

1/8" for 1.5", 1/4 for 2",2.5" case; 1/2 for 4",6"

Connection threads

Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)

Mounting

Back (Or made as panle, bottom)

Accuracy

1.5"(40mm), 2"(50mm), 2.5(63mm)-2.5%
4(100mm) and 6 (150mm)-1.6%

Pressure limitation

Steady: 3/4x full scale value
Fluctuation:2/3x full sacle value
Short time:full scale value

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 2

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 3

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 4

Product Application

1.Outdoor and severe ambient and process conditions

2.Use where harmful vibration and pulsation are present

3.Hydraulic equipment, pressure washers,oil field equipment, pumps, compressors and process systems

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 5

Company Information

Qingdao DaZeFengYang is a professional manufacturer of pressure gauges and hardware tools, and a proud member of the China National Hardware Association.

With the support of our highly skilled technical team, we strive to ensure that our pressure gauges meet both GB/T (Chinese Standards) and international quality standards. We are certified with ISO9001 and CE for all our products, which include pressure gauges, gas regulators, cutting torches, welding torches, and more.

Over the years, we have developed an impressive range of both specialized and standard products, all offered at competitive prices and with prompt delivery. Our efficient sales and after-sales service make us an attractive option for customers worldwide, particularly distributors and importers from Europe, Southeast Asia, the Middle East, America, and Australia.

We warmly invite friends and partners to reach out to us via phone or email, or to visit our company. We look forward to building a successful future together!

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 6

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 7

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 8

Packaging & Shipping

Dry Pressue Gauge Vertical 2.5" Air Pressure Gauge Bar Psi Double Scale 9

Advantages
  • Advanced Equipment and Professional Technology: We are dedicated to providing high-quality gauges using cutting-edge equipment and professional technology for customers worldwide.

  • Exceptional After-Sales Service: Our company prioritizes outstanding after-sales support, aiming for long-term trading partnerships.

  • Thorough Inspection and Superior Quality: All our pressure gauges undergo 100% inspection, and we are proud to be ISO 9001 and UL certified.

  • Timely Delivery: We ensure prompt delivery to consistently meet our customers' needs.

  • Convenient Purchasing and Cost Efficiency: As a skilled manufacturer, we offer a seamless purchasing experience, delivering high-quality products at competitive prices.

  • OEM Orders: Over the years, we have successfully fulfilled numerous OEM orders for well-known companies in the USA and European markets.
