Pressure Gauge Manometer Glycerine Filling 10 Bar G1/4" Bottom Connection

200 pieces
MOQ
$3.00/pieces 200-999 pieces
Price
Pressure Gauge Manometer Glycerine Filling 10 Bar G1/4" Bottom Connection
Features Gallery Product Description Request A Quote
Features
Specifications
Customized Support: OEM, ODM, OBM
Product Name: Glycerine Filled Pressure Gauge
Material: Stainless Steel Case, Brass Internals
Thread: 1/2''PT/NPT/G/M
Type: Measuring Instruments
Case: Stainless Steel
Highlight:

Glycerine Filling Pressure Gauge Manometer

,

G1/4" Pressure Gauge Manometer

,

10 bar Pressure Gauge Manometer

Basic Infomation
Place of Origin: Shandong, China
Brand Name: WYYW
Certification: CE,ISO
Model Number: YTN-63
Payment & Shipping Terms
Packaging Details: Each gauge packed in one paper box<br>With outer carton box <br>or packed accordiong to client's requirements
Payment Terms: T/T, Western Union
Supply Ability: 100000 Piece/Pieces per Month hydraulic jack with pressure gauge
Product Description

Pressure Gauge Manometer Glycerine Filling 10bar G1/4" bottom connection

Product Description

Pressure Gauge Manometer Glycerine Filling 10 Bar G1/4" Bottom Connection 0

Name

glycerine filled pressure gauge

Dials Size

63mm (or dail size made as demand)

Case

Stainless steel case; brass connection

Pressure

Mpa,other scale units bar, psi, kg/cm2 etc.optional

Ring

Gasket under the window

Movement

Brass

Socket

Brass

Bourdon tube

Phosphor Bronze

Dial plate and pointer

Aluminum

Window

Glass; Plastic

Connection sizes

1/8" for 1.5; 1/4 for 2",2.5" case; 1/2 for 4",6"

Connection threads

Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)

Mounting

Bottom (Or made as panle, ba)

Accuracy

1.5"(40mm), 2"(50mm), 2.5(63mm)-2.5%
4(100mm) and 6 (150mm)-1.6%

Pressure limitation

Steady: 3/4x full scale value
Fluctuation:2/3x full scale value
Short time:full scale value

Pressure Gauge Manometer Glycerine Filling 10 Bar G1/4" Bottom Connection 1





Product Application

1.Outdoor and severe ambient and process conditions

2.Use where harmful vibration and pulsation are present

3.Hydraulic equipment, pressure washers,oil field equipment, pumps, compressors and process systems

Pressure Gauge Manometer Glycerine Filling 10 Bar G1/4" Bottom Connection 2

Company Information

Qingdao DaZeFengYang is a professional manufacturer of pressure gauges and hardware tools, and a proud member of the China National Hardware Association.

Our dedicated team of technical experts works diligently to ensure our pressure gauges meet both GB/T (Chinese Standards) and international quality requirements. We are proud to have obtained ISO9001 and CE certifications for our entire product range, which includes pressure gauges, gas regulators, cutting torches, and welding torches.

Over the years, we have developed a diverse selection of both specialized and standard products, all offered at competitive prices and prompt delivery. Our efficient sales and after-sales service have made us an appealing choice for customers worldwide, particularly for distributors and importers from Europe, Southeast Asia, the Middle East, the Americas, and Australia.

We warmly invite friends to contact us via phone or email, or to visit our company. We genuinely look forward to building a prosperous future together with you.

Pressure Gauge Manometer Glycerine Filling 10 Bar G1/4" Bottom Connection 3Pressure Gauge Manometer Glycerine Filling 10 Bar G1/4" Bottom Connection 4Pressure Gauge Manometer Glycerine Filling 10 Bar G1/4" Bottom Connection 5



Advantages

1.Advance Equipment and Professional Technology : we are committed to offer the good quality gauges with advance equipment and professional technology for all over the world customers.

2.Best After-sales Service:Our company provide best after-sale service all the time , for our goal is a long trade cooperation term;

3.Serious Inspection Procedure with Excellent Quality: Our pressure gauges all are 100% inspection , we also have passed ISO9001 and UL certificated;

4.Quickly Delivery: Our company provides in-time delivery with , always satisfy customers needs;

5.Convenient Purchase and save cost: We are skillful manufacturer, so it's convenient for you to purchase , We can provide our high quality products with reasonable price;

6.OEM orders: In the past years, we have many OEM orders from very famous company in USA and European market .
