Home /Products/Electric Contact Pressure Gauge/Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection

Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection

200 pieces
MOQ
$26.00/pieces 200-999 pieces
Price
Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Bourdon Tube Pressure Gauge
Warranty: 1Y, 1 Year
Customized Support: OEM, ODM, OBM
Material: Stainless Steel
Connection: Bottom
Size: 60mm
Measuring Range: Customized
Window: Glass,Plastic
Accuracy: 1.6%
Working Voltage: AC220V, DC380V , DC24V
Thread: NPT, BSP, BSPT
Port: Qingdao
Highlight:

Stainless Steel Bourdon Tube Pressure Gauge

,

Bourdon Tube Pressure Gauge 60mm
Basic Infomation
Place of Origin: Shandong, China
Brand Name: WYYW
Model Number: YX-60
Payment & Shipping Terms
Packaging Details: Each unit in one paper box,30 boxes in one carton.As customer requested.
Supply Ability: 10000 Piece/Pieces per Month Bourdon tube Pressure Gauge
Product Description

Bourdon tube Pressure Gauge Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 0                    Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 1

Name

 Bourdon tube Pressure Gauge

Dials Size

1.5"(40mm), 2"(50mm), 2.5“(63mm), 4”(100mm) and 6“ (150mm)

Case

Black steel, ABS or chrome plated

Pressure range

0 -250Mpa,other scale units bar, psi, kg/cm2 etc.optional

Ring

Non, black steel or chrome plated

Movement

Stainless steel

Socket

Stainless steel

Bourdon tube

Phosphor Bronze

Dial plate and pointer

Aluminum

Window

Glass or Plastic

Connection sizes

1/8 for 1.5" case; 1/4 for 2",2.5" case, 3/8"&1/2" for 4",6"case

Connection threads

Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)

Mounting

Bottom,back and panel

Accuracy

1.5"(40mm), 2"(50mm), 2.5(63mm)-2.5%
4(100mm) and 6 (150mm)-1.6%

Pressure limitation

Steady: 3/4x full scale value
Fluctuation:2/3x full scale value
Short time:full scale value

Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 2Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 3Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 4Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 5Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 6Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 7Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 8                                                                 Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 9Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 10Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 11Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 12Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection 13

If you are interested in our product, please click our website:http://qddzfy.en.alibaba.com/
